MIDI messages list (firmware 1.1)
Firwmare 1.1
Available on all pedals since May 2024. When the pedal powers up the display shows 1.1 for a couple seconds.
| Control Change (CC) message | CC data | Description |
| 0 | 0-127 | 0 = bypass both channels 1-127 = turns off bypass on both channels |
| 1 | 0-127 | Set gain of both channels (not in dB) |
| 2 | 0-24 | Set gain in dB of both channels |
| 3 | 0-127 | Gain of TIP channel (not in dB) |
| 4 | 0-127 | Gain of RING channel (not in dB) |
| 5 | 0-24 | Gain of TIP channel in dB |
| 6 | 0-24 | Gain of RING channel in dB |
| 7 | 0-127 | 0 = Mute the pedal 1-127 = turns mute off |
| 8 | 0-99 | Set slew rate time (any data above 99 will return 99) |
| 9 | 1-24 | Set gain factor in dB |
| 10 | 0-127 | step UP gain 0 = will stop the gain increase 1-127 = will start gain increase |
| 11 | 0-127 | step DOWN gain 0 = will stop the gain decrease 1-127 = will start gain decrease |
| 12 | 0-127 | set Joint or Separate channels (can’t be set if the pedal is in GAIN STEP mode) 0 = set Joint mode 1-127 = set Separate mdoe |
| 13 | 0 | Toggles between TIP and RING channel selection If SEPARATE channel is set |
| 14 | 0-127 | When JOIN channels is set, change gain of both channels |
| 15 | 0-24 | When JOIN channels is set, change gain of both channels (in dB) |
| 16 | 0-127 | When SEPARATE channels is set and TIP is selected, change gain of TIP channel |
| 17 | 0-127 | When SEPARATE channels is set and RING is selected, change gain of RING channel |
| 18 | 0-24 | When SEPARATE channels is set and TIP is selected, change gain of TIP channel (in dB) |
| 19 | 0-24 | When SEPARATE channels is set and RING is selected, change gain of RING channel (in dB) |
| Program Change | Message Data | Description |
| 0 | – | Load preset 1 |
| 1 | – | Load preset 2 |
| 2 | – | Load preset 3 |
MIDI message list (firmware 1.0)
| CC message | CC data | Description |
| 0 | 0-127 | 0 = bypass both channels 1-127 = turns off bypass on both channels |
| 1 | 0-127 | Set gain of both channels (not in dB) |
| 2 | 0-24 | Set gain in dB of both channels |
| 3 | 0-127 | Gain of TIP channel (not in dB) |
| 4 | 0-127 | Gain of RING channel (not in dB) |
| 5 | 0-24 | Gain of TIP channel in dB |
| 6 | 0-24 | Gain of RING channel in dB |
| 7 | 0-127 | 0 = Mute the pedal 1-127 = turns mute off |
| 8 | 0-99 | Set slew rate time (any data above 99 will return 99) |
| 9 | 1-24 | Set gain factor in dB |
| 10 | 0-127 | step UP gain 0 = will stop the gain increase 1-127 = will start gain increase |
| 11 | 0-127 | step DOWN gain 0 = will stop the gain decrease 1-127 = will start gain decrease |
